AP50F2 fire-extinguishing foam tanker integrates functions of a fire-extinguishing water tanker with a fire-extinguishing foam tanker and is mainly used in cities. With water mixed with foam A and B based on a certain matching ratio, AP50F2 greatly improves fire extinguishing efficiency. At the same time, AP50F2 is equipped with a light generator system, a traction system, emergency rescue equipment, and protective equipment. Therefore, AP50F2 is a kind of firefighting truck with functions of lighting, traction, rescue, and fire protection configured.

AP50F2 is used for firefighting in high-rise buildings, residential buildings, shopping malls, etc. and has been the first choice for rescue in outstanding public security accidents, such as urban traffic accidents, building collapses, earthquake disasters, and personnel distress, etc.



Advantages & Highlights:

1.Strong single-vehicle operational capability

AP50F2 uses a Sino truck T5 chassis with double-row cabs, has strong dynamic performance, safe and reliable quality, allows 6 passengers, and applies to centralized delivery of fire-fighting combination.

2.Fire control system is convenient and efficient, and has high safety.

A full-integration one-touch controlled compressed air foam system is easy to operate. Electric remote-control water cannon.

3.Security protection settings and high intelligence

The vehicle adopts a variety of safety protection devices to ensure that driving, rescue, and firefighting are safe and reliable. With details considered, multilayer storage compartment structures use light bars to realize multi-layer space lighting to meet usage requirements.

4.Intelligent self-water supply function

Intelligent tank water rise preventing technology: A water filling nozzle can be opened or closed according to liquid level. This effectively prevents occurrence of water rise in tanks and realizes continuous uninterrupted water supply fire extinguishing. It can automatically control and adjust engine speed and pump working pressure, automatically control pressure of water flow. Automatic water supply is performed according to set constant voltage and flow.

5.Automatic water supply

The vehicle can automatically control and adjust the engine speed and pump working pressure; Automatic control valve opening and closing and throttle add and subtract, according to the set constant pressure remote automatic water supply operation.


Item

Unit

Parameters

Overall dimensions

Length

mm

9130

Width

mm

2500

Height

mm

3780

Axle base

mm

4500

Wheelbase

mm

1980/1850

Front/rear suspension

mm

1430/2680

Front/rear extension

m

405/115

Maximum speed

km/h

≥95

Minimum turning diameter

m

≤19

Braking length (full load, initial braking speed 30 km/h)

m

≤10

Approach Angle/Departure Angle

°

≥18/≥9

Maximum climbing ability

%

≥30

Rated fire extinguishing agent

Full load weight

Water

kg

4100

Class-B foam

kg

350

Class-A foam liquid

kg

500

Curb weight

Total weight

kg

11350

Front axle

kg

4600

Rear axle

kg

6750

Maximum allowable value

Total weight

Total weight

kg

16750

Front axle

kg

6100

Rear axle

kg

10650

Type

ZZ5207TXFV471GE5

Type

II

Driving type

4×2

Manufacturer

Sinotruk Group

Engine

Type

MC07.34-50

Fuel type

diesel

Displacement/Power

mL/kW/kW

6870/248/245

Emission level

Nation V

Manufacturer

Sinotruk Group

Steel spring number

3/32

Tire size

12.00R20

Number of tires (excluding spare tires)

6

Passengers allowed in the cab

2+4
